IMT 5525

Chapter 4 Parts 49
71410928 CYLINDER DATA
EXTENDED LENGTH
276.13" with both
cylinders extended
RETRACTED LENGTH
126.13"
TOP CYLINDER (ITEM
#3)
2.5" O.D., 1.7" I.D., 72.00"
STROKE
TEST PRESSURE
3500
BOTTOM CYLINDER
(ITEM #2)
2.7" O.D., 1.7" I.D., 78.00"
STROKE
OPERATING PRESSURE
3000 PSI
71410928 PARTS LIST
ITEM
PART #
DESCRIPTION
QUANTITY
1.
001EE0006
HYDRAULIC LINE, EXT CYLINDER
2
2.
71410930
CYLINDER, 2.7/1.7 78.00 S
1
3.
71410931
CYLINDER, 2.5/1.7 72.00 S
1
4.
103MG0006
CLEVIS PIN
1
5.
106EA0006
NUT, #6 FLARELESS TUBE
4
6.
106EB0007
FERRULE, #6 FLARELESS TUBE
4
7.
108BL0002
LOCK NUT, 1.25-12 UNF
1
8.
108LZ0002
CLIP, HITCH PIN
2
9.
108NZ0005
CLAMP, HOSE
6
REV. B 20060111
