IMT 5525

Chapter 4 Parts 63
70570771 PARTS LIST
24.
71411826
MOTOR GASKET (NOT SHOWN) (PART OF
#74 SEAL KIT)
1REF
25.
LOCKWASHER (1/2 ZINC)
2
26.
CAPSCREW (1/2 NC X 1-1/4 G8 ZINC)
2
27.
OIL SEAL (PART OF #74 SEAL KIT)
1REF
28.
71411143
BALL BEARING
2
29.
SPRING LOCATOR
1
31.
O-RING (PART OF #74 SEAL KIT)
1REF
32.
OIL SEAL (PART OF #74 SEAL KIT)
1REF
33.
LOCKWASHER (5/16 ZINC)
6
34.
CAPSCREW (5/16 NC X 1 GR8 ZINC)
6
35.
SPRING PLATE
1
36.
U-CUP SEAL (PART OF #74 SEAL KIT)
1REF
37.
VENT PLUG
1
38.
BRAKE PLATE SPACER
1
40.
73540372
VALVE, BRAKE (INCL 72,73)
1
43.
BRAKE COUPLING
1
44.
71411147
FRICTION DISC
8
45.
71411827
BRAKE DISC
9
46.
O-RING (PART OF #74 SEAL KIT)
1REF
47.
71411146
SPRING
12
48.
73511057
HYD MOTOR
1
49.
PLUG (PART OF #74 SEAL KIT)
1
50.
IMT NAMEPLATE (NOT SHOWN)
1
51.
DRIVE SCREW (NOT SHOWN)
4
53.
LOCKWASHER (7/16 ZINC)
6
54.
CAPSCREW (7/16 NC X 1 GR8 ZINC)
6
55.
71411150
CABLE WEDGE (NOT SHOWN)
1
57.
CAPSCREW (5/16 NC X 3 GR8 ZINC)
4
58.
ELBOW FITTING
2
59.
HOSE ASSEMBLY
1
60.
WASHER, HARDENED (5/16 ZINC)
4
70.
SUN GEAR THRUST BUTTON
1
71.
PIPE PLUG
2
72.
73540287
COUNTERBALANCE VALVE CARTRIDGE
1
73.
73540371
CHECK VALVE
1
74.
94744147
SEAL KIT (INCL. 24,27,31,32,36,46,49)
1
