82 Model 5525-6025-6625 Parts & Specifications Manual Part # 99904215
51719470 HANDLE ASSEMBLY WIRE FUNCTIONS
SOLID/STRIPE
FUNCTION
A
YEL/BLK
ROT CW
B
ORN/BLK
EXT OUT
C
BLU/BLK
WINCH DN
D
RED/BLK
WINCH UP
E
ORN/RED
-
F
BRN
EXT IN
G
BRN/RED
ENG START
H
BLU/RED
-
J
BLK/RED
ENG SPEED
K
BRN/BLK
ROT CCW
L
RED
POWER
M
BLU
ENG STOP
N
ORN
LOWER DN
O
BLK/ORN
SOL POWER
P
YEL
LOWER UP
Q
BRN/BLU
-
R
YEL/RED
-
S
BLK
CRANE
T
BLK/BLU
CPRSR
U
RED/BLU
SIMULTANEOUS
V
BLU/ORN
-
W
ORN/BLU
-
X
YEL/BLU
-
-
RED/RON
-
51719470 PARTS LIST
ITEM
PART #
DESCRIPTION
QUANTITY
1.
89044214
WIRE 18GA GRN
1.61 FT
2.
60119335
CONTROL HANDLE
1
3.
60111141
TRIGGER (PART OF 11)
1REF
4.
60119277
COVER
1
5.
70034306
BACK COVER
1
7.
77044196
STRAIN RELIEF 3/4
1
8.
77044621
PIN
23
9.
70394447
DECAL-DGR RC ELECTRO SM
1
10.
70396719
DECAL-CTRL
1
11.
70394183
TRIGGER ASM (INCL 3)
1
14.
72061009
SHT MTL SCR #6X3/4 PH
8
15.
77040051
TERM-SPRSPD #8 16-14GA
31
16.
77040371
TOGGLE SWITCH SPST
2
17.
77040372
TOGGLE SWITCH SPDT
4
18.
77040373
TOGGLE SWITCH SPST
2
19.
77040374
TOGGLE SWITCH SPDT
1
20.
77044579
CONNECTOR
1
21.
89044100
CABLE 18GA 24WIRE (NOTE: MUST ORDER
40 FT)
40 FT
REF
51717817
TETHERED CABLE, 40' (INCL 8, 15 (24) 20, 21,
25)
1
22.
77040147
TERM-FSLPON 1/4TAB 22-18
3
