IMT 5525 Parts & Specifications

Parts 91
Installation Notes:
1 Tie stabilizer housing tube into the structural support of the crane.
2 Items #18, #25, and quantity (1) of #21 are installed behind the back wall of the crane box to support hose
assembly #2 as it passes behind the crane box.
3 Items #18, #25, and quantity (1) of #21 are installed under belly pan of floor to support hose assembly #3 as it
passes under belly pan.
4 #38 spiral wrap is installed around #3 and #4.
31712740 PARTS LIST
ITEM
PART #
DESCRIPTION
QUANTITY
1.
3B205010
CYLINDER
2
2.
51394931
HOSE-FF 1/2X98 OAL
1
3.
51395552
HOSE-FJ 1/4X135 OAL
2
5.
51714813
VALVE BANK, 2 SECT (INCLUDES #40)
1
6.
51396280
HOSE-FJ 1/4X96
2
7.
52070138
PIN WELDMENT
1
8.
52712735
ARM, ADJUSTABLE
1
9.
52712736
ARM, STATIONARY
1
10.
60010351
SPRING "T" PIN
1
11.
51396184
HOSE-FF 1/2X159 OAL (8-8) (PART OF #51)
1
12.
51396282
HOSE-FF 3/4 X51 OAL (12-12) (PART OF #51)
1
13.
72053758
ELBOW #4MSTR #4MJIC 90°
2
14.
72053764
ELBOW #10MSTR #8MJIC 90°
1
15.
72060025
CAP SCR 5/16-18X1 HHGR5Z
3
16.
72060107
CAP SCR 1/2-13X8 HHGR5
1
17.
72060155
CAP SCR 5/8-11X3.5 HHGR5
4
18.
72060833
SCR-THD CUT 5/16-18X3/4 HWH-1 (SEE
NOTE)
2
19.
72062080
NUT 1/2-13 HEX NYLOC
1
20.
72062091
NUT 5/8-11 HEX NYLOC
4
21.
72063002
WASHER 5/16 FLAT
5
22.
72063005
WASHER 1/2 FLAT
2
23.
72063027
MACHY BUSHING 5/8X14 GA NR
2
24.
72066185
COTTER PIN
1
25.
72066582
CLAMP-UMP 20 (SEE NOTE)
2
26.
72532358
ADPTR #8MSTR #8MJIC
1
27.
72532365
ADPTR #10MSTR #12MJIC
1
28.
72531205
TEE-MALE JIC 3/4-16 1/2 TUBE
1
29.
72532658
ELBOW #8MJIC #8FJIC SW
1
35.
72532696
ELBOW #12MJIC #12FJIC SW
1
37.
76391511
DECAL-UP & DOWN STAB. R&L
1
38.
89034049
SPIRAL WRAP, BLK (SEE NOTE)
4'
39.
99900644
MANUAL-AUX STABILIZER
1
40.
51731580
HANDLE ASM (INCL. 34-41) (PART OF 5)
2REF
41.
70142648
PIVOT-LEVER (PART OF #40)
2REF
42.
70142650
LEVER SUPPORT (PART OF #40)
2REF
43.
70142651
LEVER-CONTROL HANDLE (PART OF #40)
2REF
44.
71392269
KNOB-CONTROL HANDLE (PART OF #40)
2REF
45.
72062021
NUT 5/16-18 HEX JAM (PART OF #40)
2REF
46.
72062024
NUT 1/2-13 HEX JAM (PART OF #40)
2REF
47.
72066162
COTTER PIN (PART OF #40)
4REF
48.
72661204
CLEVIS PIN (PART OF #40)
4REF
49.
72532972
ADPTR #8MJIC #12FJIC
1
50.
72532980
ADTPR PR SW IN-LINE JIC 3/4
1
51.
52712734
STAB HOUSING 7X5
1
