I/O Module(s) Setup Page 20 - 3
20
CAUTION
DO NOT use Leak Detection Sensors (i.e. TSP-ULS) with these assemblies
or input modules. These are not Intrinsically Safe (I.S.) or approved for this use.
LINE LEAK DETECTOR For input modules only
MODE (Change mode if wrong)
LN NAME N
LINE N
(input line #)
FAIL OG (N may not equal the channel number)
LINE TEST FAIL OUTPUT GROUP N
NONE
(A to FF or ALL) Assign alarm to Output Group N.
(document the assignment in Worksheet # 20-2)
OUTPUT NORMALLY OPEN (output module closes on alarm)
MODE (Change mode if wrong)
OUT GRPS Select / assign output group(s) to activate
Channel N output module on alarm.
I / O MODULE OUTPUT GROUPS N GROUP
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
A
1 32
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z AA BB CC DD EE FF
Fill–in Output Module Channel N – Alarm Group Assignments in following page(s)
OUTPUT NORMALLY CLOSED (output module opens on alarm)
MODE (Change mode if wrong)
OUT GRPS Select / assign output group(s) to activate
Channel N output module on alarm.
I / O MODULE OUTPUT GROUPS N GROUP
– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
A
1 32
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z AA BB CC DD EE FF
Fill–in Output Module Channel N – Alarm Group Assignments in following page(s)
3
4
5
NOTE
☞
The 24
TH
group
(Group X) is shown
assigned
Y
Example
I/O
Output Module — OUTPUT GROUP Assignment (shown filled-in)
ABCDEFGH I JKLMNOPQRSTUVWXYZA AB BC CD DE EF F
Y YYY Y
I / O MODULE OUTPUT GROUPS N GROUP
Y – – Y Y Y – –
– – – – – – – – – – – – – – – Y – – – – – – – – X
1 32
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z AA BB CC DD EE FF
Press:
M1
to move the cursor left
ï
M2
to move the cursor right
ð
M4
to backspace (delete) one character to the left
ï
UP / DOWN
▲▼ to select (Y for yes assigned, or
–
(dash) for no not assigned)
ENTER
to store the setup into the system memory
— Continued on next page —
