iNetVu
®
Mobile Installation Manual Page 16 of 93
3.3 Installation Overview
1. Unpack the Mobile Platform and reflector.
2. Attach reflector to Mobile Platform (iNetVu® 1200/1500/1800 Mobile System only. See
section 4.2 and 4.3).
3. Locate a suitable mounting site with adequate clearance.
4. For Direct Roof Installation:
a. Mark the position of the Mobile Platform ensuring the front / back orientation is
correct.
b. Pre-seal the roof.
c. Place the Mobile Platform in position.
d. Drill pilot holes if necessary and secure with screws. Note that the dish may
obscure some of the mounting holes.
e. Install the corner screws.
f. Raise the dish either via Handheld Controller or iNetVu
®
Mobile software.
g. Attach Mobile Platform to roof.
For Thule Rack Installation:
i. Attach Mobile Platform to Thule Rack
5. Run Power, Motor Control, Coaxial, Sensor cables.
6. Connect iNetVu
®
Controller, Satellite Modem, PC and Mobile Platform.
7. Install iNetVu
®
Mobile Software.
8. Configure to correct service and operate (see Mobile User Manual for more detail)
