3.6 Alternative Installation to Vehicle Using Thule® Racking System
For pallet mounting, the vehicle must be fitted with Thule
®
components that are matched to
customer’s specific vehicle. The cables are fed through a specially drilled hole and clamped
in a special foam grommet in order to prevent chaffing of the cables. (Note: The Thule feet
and connection to vehicle must be checked regularly for a secure fit with no loose fittings).
Note that 3 Thule bars, minimum are required.
1. Remove the top and sides of the shipping crate.
2. Remove any internal bracing and all packaged parts.
The iNetVu system is an extreme load and must
therefore be handled correctly and with care. If it is NOT
handled correctly, it could cause a potentially hazardous
situation that could result in death or serious injury.
3. Remove the bolts attaching the iNetVu® system to the bottom of the shipping crate
and remove the iNetVu® system. Note that the iNetVu® is shipped pre-assembled on
its mounting plate.
4. Install Thule components to vehicle.
Note: The iNetVu® system is oriented with back of the reflector facing the front of
vehicle. With least four people, raise and position the system on the installed Thule
rack. Under no circumstances should one person attempt this alone.
5. Align mounting angles and sides of pallet and secure with at least 6 “U” brackets – not
included with the iNetVu® Mobile Systems (a minimum of 2 per bar).
6. Run the cables neatly inside the vehicle to the iNetVu® Controller. Connection to the
iNetVu
®
Controller is in the Controller Manuals.
7. Congratulations! Installation has been successfully completed.
