If this is the first time working with the iNetVu® Mobile Platform it
is highly recommended that you read the entire manual to
familiarize with the proper procedure for connecting the cables to
the controller and iNetVu
®
software operation.
Required Materials:
• 1.5 m Reflector
• 1500 Mobile Platform
• Wrench Set
• Handheld Controller (Optional)
• 1.5m Reflector Mounting Hardware
Procedure:
Use the following steps to attach a 1.5m Reflector to an iNetVu
®
1500 Mobile Platform
Please note that it is strongly recommended that at least 2 people are assisting in the installation of the
reflector.
1. Remove reflector from crate and any packing materials on the Mobile Platform.
2. Raise the Mobile Platform to approximately 30 using the iNetVu
®
Mobile
Software/Controller or the Handheld Controller. For more information regarding the
use of the iNetVu
®
Mobile Software and its installation, please refer to the iNetVu
®
System Manual.
3. With the assistance of at least one other person, align the reflector with the four (4)
mounting holes located on the Elevation assembly.
