iNetVu
®
Mobile Installation Manual Page 17 of 93
3.4 Mobile Platform Front / Back Orientation
The iNetVu
®
Mobile Platform is polarized and must be
mounted so that the Azimuth Plate of the Mobile Platform
faces the front of the vehicle on which it is mounted. The end
with the reflector faces the rear of the vehicle. Failure to
adhere to these requirements could cause the Mobile Platform
to detach from the vehicle at high speed.
Fig. 1: Front / Back orientation of iNetVu
®
Platforms
Front of Vehicle
