iNetVu
®
Mobile Installation Manual Page 60 of 93
4.5 Installing BUC to iNetVu® 980 Mobile Platform using Universal
Bracket Kit
This procedure describes the steps involved for installing a Block Up Converter (BUC) to the
iNetVu® 950 / 980 Mobile Platform.
Required Materials:
• iNetVu
®
980 Mobile Platform
• BUC
• Universal Transmitter Mounting Bracket Kit
• Four (4) ¼ Flat Washers
• Four (4) ¼.20 NYL Nuts
• Four (4) S/S 4.50 inch Hex Bolts
• Four (4) ¼ Split Washers (only if ¼.20 Nuts are not NYL)
• Two (2) S/S Hex Bolt 5/16” x 3” (ISIS BUC ONLY)
Procedure:
1. Place and secure the BUC on the underside of the Feed Arm.
2. If you are using a larger BUC (2W and up), you may need to use the outer holes of the
bracket, to secure the BUC to the Feed Arm.
