iNetVu
®
Mobile Installation Manual Page 18 of 93
3.5 Direct Installation to Vehicle
1. Remove the top and sides of shipping crate.
2. Remove any internal bracing and all packaged parts.
3. Remove the bolts attaching the iNetVu Mobile System to the bottom of crate and
remove the iNetVu® Mobile System from its shipping base. Note that iNetVu® is
shipped pre-assembled on its mounting plate.
The iNetVu system is an extreme load and must
therefore be handled correctly and with care. If it is NOT
handled correctly, a potentially hazardous situation can
arise that could result in death or serious injury. The
Roofing must be assessed and capable of handling the
load prior to installation.
4. With the aid of at least four people, raise and position the system on the roof. The
system must be handled and supported at both ends. Under no circumstances should
one person attempt this alone.
Note: Ensure that the front/back orientation of the Mobile Platform is correct.
5. Maneuver the Mobile Platform over the mounting position on the vehicle and verify that
the proper clearance space is available. Visually check that the dish arm will not hit
any other mounted antenna or other device such as air conditioners as it rotates.
See the following figure for Roof Clearance Requirements:
