iNetVu
®
Mobile Installation Manual Page 55 of 93
2. Ensure the Feed Horn aligns to center of POL cage.
Fig. 43: Feed Horn Installed
3. The Feed Horn mounting shafts will only fit one way, slide into place one end at a time
and tighten screws.
4. Install Feed Horn roll bar and tighten (4) screws.
Fig. 44: Feed Horn (guard) roll bar installation
