iNetVu
®
Mobile Installation Manual Page 57 of 93
7. Connect Tilt sensor and motor cables, ensure exterior cables are run along the side
and enter the shell from the allocated slot.
8. Ensure the cables are tucked neatly and install top cover.
9. Install waveguide onto OMT; ensure waveguide and OMT grooves are NOT crossed.
The grooves should be aligned for proper signal transmitting. See section 4.12 for
waveguide installation.
10. Check all connections and fasteners on the POL Cage Assembly.
11. Congratulations you have successfully installed the Ku POL Feed Horn Assembly onto
the 1.8M iNetVu™ Driveaway Antenna.
