Fig. 53: Attaching BUC using Universal Transmitter Brackets
Fig. 54: Correctly mounted and secured BUC with ¼” space between BUC
and Feed Arm Bar
4. Connect ‘Tx’ Coaxial cable to the BUC.
Polarization
Cage End
Reflector End
