User’s manual of CLEO Patient Monitor
- 23 -
NIBP MONITORING INITIALIZATION
After opening the host machine, check the information area of the screen before NIBP
monitoring. If you see message “NIBP selfcheck OK!”, then the NIBP module is working,
and you can begin NIBP monitoring. Any NIBP monitoring taken before the information
indicating is invalid; if you see “NIBP selfcheck error”, then the NIBP module is not
working. Press the START/STOP button to run the self-check or machine-open again. If
the error persists, contact a servicing engineer.
NIBP PARAMETER SETUP
Touch the NIBP Parameter Area to open the NIBP Setup menu.
NIBP Setup
Choose Color
Pressure Unit
Patient Type
Inflation Mode
Time Interval
Factory Setup
STAT
Manual
Auto
Neonatal
Adult
Pediatric
Alarm Switch
Alarm Setup
NIBP List
Figure 7: Tree Diagram for NIBP Setup Menu
This menu has the following settings:
DISPLAY COLOR
Choose from Yellow, White, Blue, Red, Green and Cyan. The default setting is Green.
[WARNING]

The width of the cuff should be either 40% of the limb circumference (50% for
neonates) or 2/3 of the upper arm length. The inflatable part of the cuff should be
long enough to encircle 50-80% of the limb. Using the wrong cuff size can cause
erroneous readings. If you are unsure about which cuff size to use, use a larger
cuff.
 Make sure that the cuff edge falls within the range of 〈-〉. If does not, then change
to a more suitable cuff.
 Connect the cuff to the air hose. The limb chosen for taking the measurement
should be placed at the same level as the patient’s heart. If this is not possible you
should apply the following corrections to the measured values:
 If the cuff is placed higher than the heart level, add 0.9mmHg (0.12kPa) for each
inch of difference.
 If it is placed lower than the heart level, deduct 0.9mmHg (0.12kPa) for each inch
of difference.
