User’s manual for CLEO Patient Monitor
- 52 -
DIA 15
～
200 (mmHg)
Neonatal Mode
SYS 40～135 (mmHg)
DIA 15
～
100 (mmHg)
Resolution:
1mmHg
Pressure Accuracy:
Maximum Mean Error: ±5 mmHg
Maximum Standard Deviation: 8 mmHg
Overpressure Protection:
Adult Mode 280 (mmHg)
Neonatal Mode 150 (mmHg)
Alarm Limit:
SYS 30
～
240 mmHg
DIA 15
～
180 mmHg
QUICK TEMPERATURE
Standards:
Meets performance standards
of EN 12470-3:2000
，
ASTM E1112:2006
Temperature Measurement Range:
30
℃～
43
℃ (86℉～
109
℉)
Typical Measurement Times
(after insertion into measurement site):
Oral (Quick Mode): 3
～
5 s (non-fever
temps), 8～10 s (fever temps)
Oral (Standard Mode): 6～10 s
Axillary Mode: 8～12 s
Rectal Mode: 10～14 s
Direct Mode (All Sites): 60
～
120 s
Accuracy:
A Standard Prediction Mode reading and a
Direct Mode reading will differ by
less than ±0.2°C (±0.4°F) on 98% of tested
patients
CO2
Mode of Sampling:
Sidestream
Measurement Technology:
Infrared Absorption
Standards:
ISO 21647
Principle of Operation:
Non-dispersive Infrared (NDIR) single beam
optics, dual wavelength, no moving parts.
Initialization Time:
Capnogram displayed in less than 20 s, at an
ambient temperature of 25℃, full specifications
within 2 minutes.
CO
2
Measurement Range:
0
～
150 mmHg (0
～
19.7 %, 0
～
20 kPa)
(Barometric Pressure supplied by Monitor)
CO
2
Calculation Method:
BTPS (Body Temperature Pressure Saturated)
Response Time:
<3 s ( includes transport time and rise time)
CO
2
Resolution:
0
～
69 mmHg: 0.1 mmHg
70
～
150 mmHg: 0.25 mmHg
CO
2
Accuracy:
0
～
40 mmHg: ± 2 mmHg
41～70 mmHg : ± 5 % of reading
71～100 mmHg: ± 8 % of reading
101～150 mmHg: ±10 % of reading
Above 80 breath per minute ± 12 % of reading
[NOTE]:Gas temperature at 25℃.
CO
2
Stability:
Short Term Drift: Drift over four hours shall not
exceed a maximum 0.8 mmHg.
Long Term Drift: Accuracy specifications will be
maintained over a 120-hour period.
CO
2
Noise:
RMS noise of the sensor shall be less than or
equal to 0.25 mmHg at 5 % CO
2
Sampling Rate:
100 Hz
