Installation Manual
58 Apollo devices supported by the control panel
B.14 Modules with Isolators
B.15 Loop limitations
Use suitably sectioned shielded twisted cable for the loop wiring. Connect the shield to earth using
terminal 3 or 6, connect it to one end of the loop only.
In order to allow the loop to function properly, you must section the device connection cable in such
way that any voltage drop along does not exceed 8 V. The following table shows the minimum wire
sections for the Loop wiring with regard the distance between the Loop-O terminals and the most
distant device:
B.16 Configuring APOLLO devices
Every APOLLO device requires an address to identify it on the loop. Apollo devices must be addressed
manually, as follows.
55000-821 XP95 DIN RAIL Switch Monitor Plus DIN RAIL Module with 1 Delayed Input and Reset Output for
waterflow detectors (waterflow alarm)
55000-822 XP95 DIN RAIL Switch Monitor DIN RAIL Module with 1 Input
55000-812 XP95 DIN RAIL Zone Monitor (with
Isolator)
DIN RAIL Interface Module for Conventional Zones (with isolator)
55000-826 XP95 DIN RAIL Sounder control Unit DIN RAIL Module with 1 sounder control output externally-powered
55000-802 XP95 DIN RAIL Dual Isolator DIN RAIL Dual Isolator
Model Name Description
55000-841 XP95 Switch Monitor Plus with Isolator DIN RAIL Module with 1 Delayed Input and Reset Output for
waterflow detectors (waterflow alarm)
55000-843 XP95 Switch Monitor with Isolator Single Input Module with Isolator
55000-845 XP95 Zone Monitor with Isolator Interface Module for Conventional Zones with Isolator
55000-847 XP95 Input/Output module with
Isolator
Module with 1relay output + 1 Supervised Input + 1 Non-
supervised Input (optoisolated)
55000-849 XP95 Output unit with isolator Module with 2 relay outputs with isolator
55000-852 XP95 Sounder control unit with isolator Module with 1output for self-powered siren (optoisolated)
up to 500 m
min. 1 mm
2
up to 1000 m
min. 1.5 mm
2
up to 1500 m
min. 2 mm
2
up to 2000 m
min 2.5 mm
2
