InkJet DuraCode Series - 2.3 Printhead; 2.4 Ink Core

Page 5
2.3 Printhead
Last Chance Filter
Nozzle
Charge Electrode
Nozzle Connector
Printhead type
Nozzle Connector
Deflection Plate
Gutter Pipe
2.4 Ink Core
Condenser
Cover
*
Exhaust Air
Switch
Manifold
Gear Pump
Drain Pipe
Filter
Addition
Pump
* Exhaust Vent Plug
Flushing
Pump
Ink Core(Front View) Ink Core(Back View)
*
Please remove the exhaust vent plug and turn on exhaust
air switch before use.
