3 TECHNICAL DATA
3.1 Dimensions
The dimensions below are for the BV50 showing 300, 550, 800 and 1050 note
cashbox. For dimensional drawings contact support@innovative-technology.com
3.2 Weight 0.85kg
3.3 Environmental Requirements
Environment
Minimum
Maximum
Temperature
+3°C
50°C
Humidity
5%
95% Non-condensing
3.4 Power Requirements
3.4.1 Supply Voltages
Supply Voltage
Minimum
Nominal
Maximum
Supply Voltage (V DC)
+ 10.8 V DC
+ 12 V DC
+ 13.2 V DC
Supply Ripple Voltage
0 V
0 V
0.25 V @ 100 Hz
