high and must be set to low (GND) to enable banknote acceptance. If no Inhibit is
set to low (GND) the Master Inhibit is set and the [Product Name] is disabled.
6.8.4 Escrow Control
The BV50 has a single note escrow facility. This allows the BV50 to hold onto the
note once validated, and then only stack the note into a cashbox when the host
machine confirms that the Vend operation has been completed. Please see below:
6.8.5 Low Power Mode
The Low Power Mode can be used to reduce the power consumption of the BV50
when idle. When the Low Power Mode option is set, the BV50 goes into the Low
Power Mode after about 6 seconds after the BV50 is powered up and remains in this
state until a note is entered. Following a note insertion, the BV50 returns to Low
Power Mode approximately 1 second after a credit is given or note is rejected.
Please refer to Appendix 11.6 for timing diagram and further details.
In Low Power Mode the front
sensor is checked every second
which can lead to a delay in
accepting the note when it is
presented!
Configuration button functions are
only available during power up
before the BV50 goes into Low
Power Mode!
