Interrupting the download process
can result in the unit entering a
non-functional state, once the
process has started it cannot be
halted.
When completed the unit will restart and a pop-up box will appear saying Device
Programming Complete.
5.4.2 DA3
5.4.2.1 General Description
The DA3 is a hand-held validator programming system that enables the user to re-
program ITL banknote validators in the field, without the use of a PC. Dataset and
firmware files for different validator models can be stored on the DA3. Once
programmed the user can update or override existing software as well as test the
functionality of the validator, away from the host machine.
5.4.2.2 System Requirements
• Windows XP SP3 or above
• .Net Framework 4
• 256mb ram
• 50mb hard disk free
• Connected DA3 with active com port
• Data Flash Card (PA01121)
optional
5.4.2.3 Re-programming via DA3
To program the DA3 Device Programming system (DPS) needs to be used, this can
be downloaded from our website. The DA3 connects to the PC through the USB port
Once the software is installed import the dataset into the DPS before uploading it to
the DA3 internal memory.
