6.6.3 Inhibit Control
The Inhibits can be used to either enable or disable the acceptance of those
banknotes programmed on channels 1, 2, 3 and 4. The Inhibits are internally held
high and must be set to low (GND) to enable banknote acceptance. If no Inhibit is
set to low (GND) the Master Inhibit is set and the BV50 is disabled.
6.6.4 Escrow Control
The BV50 has a single note escrow facility. This allows the BV50 to hold onto the
note once validated, and then only stack the note into a cashbox when the host
machine confirms that the Vend operation has been completed. Please refer to
Appendix 11.5 for timing diagram and further details.
6.6.5 Low Power Mode
The Low Power Mode can be used to reduce the power consumption of the BV50
when idle. When the Low Power Mode option is set, the BV50 goes into the Low
Power Mode after about 6 seconds after the BV50 is powered up and remains in this
state until a note is entered. Following a note insertion, the BV50 returns to Low
Power Mode approximately 1 second after a credit is given or note is rejected.
Please refer to Appendix 11.6 for timing diagram and further details.
In Low Power Mode the front sensor is checked every
second which can lead to a delay in accepting the note
when it is presented!
Configuration button functions are only available
during power up before the BV50 goes into Low Power
Mode!
6.6.6 IF10 Interface
The IF10 is an interface that allows serial SSP to be used in machines without the
need of updating the machine software. The IF10 is connected between the BV50
and the host machine. The IF10 communicates with the BV50 in serial SSP which
gives more security along the length of the cable. The IF10 should be mounted close
to the host machine control board where the IF10 converts to the parallel
connection.
