Start
Pin 10 Held Low
Pulse Received?
Check Credit Line/s
No
Want to Accept Note?No
No Response
in 30s
Yes
Hold Pin 10 High Note Rejects
Pulse Received?
Check Credit Line/s
No
Credit
End
Hold Pin 10 Low
Channel Inhibit High
Yes
Yes
No Response
in 30s
Note Forcibly
Removed By
Customer
Caution!
Only book the credit on the second
Vend pulse!
11.5.1 Escrow Timing Diagram
