The BV50 is now in trusted mode for
30 seconds. Once the keys are
negotiated with the host, disconnect
the BV50 validator from the cable,
close the head, and re-connect. Plug
the validator back in to the host and
your validator should now be installed
and configured.
11.5 Escrow Control
The BV50 has a single note escrow facility. This allows the BV50 to hold onto the
note once validated, and then only stack the note into a cashbox when the host
machine confirms that the Vend operation has been completed. If no confirmation of
the Vend is received, then the note will be returned to the user after 30 seconds. If
the host machine itself aborts the transaction by setting the corresponding inhibit
input high, the note is returned immediately. The sequence of operation is as
follows:
