4.9 Basic Operation
The NV11 validator is a device that can accept, validate and store 300 or 600 bank
notes of mixed denominations, and works with any NV9USB currency dataset created
by Innovative Technology Ltd.
Validated bank notes are stored in the NV11’s cashbox, and bank notes accepted by
the validator are not visible once inside the unit and can only be taken out of the
cashbox manually.
The NV11 validator has inbuilt fault detection facilities. If there is a configuration or
other error either the Note Float module status LED, or the NV9USB validator head
front bezel will flash in a particular sequence; a summary of the Flash Codes for both
units is shown below:
NV9USB Bezel Flash Codes:
Flashes
Indicated Error
Comments
Long
Short
0
0
None
1
2
Note path obstructed
Remove obstruction and
follow the cleaning
procedure in Section 2 of
this manual set
3
Unit not initialised
Contact ITL technical
support
2
2
Cash box problem
Check that the cash box
note plate is free to move
and the stacker mechanism
is in the home position
3
1
Firmware checksum
error
Download new firmware
2
Interface checksum
error or unable to
set programmed
interface
3
EEPROM checksum
error
4
Dataset checksum
error
5
Incompatible
firmware
Check the validator
firmware is compatible with
the Note Float module
4
1
Power supply too
low
Check power supply
2
Power supply too
high
