NV11 Manual Set – Section 4 3
Copyright © Innovative Technology Ltd 2012 GA963-2
4. MECHANICAL AND ELECTRICAL MANUAL
This section is one part of a complete manual set: Design Engineers who are
designing a host machine cabinet, or looking to integrate the NV11 validator into an
existing cabinet would need to read this section. This section contains the all the
mechanical and electrical information a designer needs to effectively integrate the
NV11 validator into a host machine.
4.1 Introduction
The NV11 validator is made up of four basic components: an NV9USB validator head,
Note Float module, removable bezel and a cashbox (as shown below):
The NV11 is a device that can accept, validate and store 300 or 600 bank notes of
mixed denominations, and also has the capability of storing a further 30 notes in the
Note Float module for future payout.
Up to 16 different denominations of bank note can be accepted and stacked, and the
Note Float module can be programmed to store and dispense 30 single denomination
notes.
