NV11 Manual Set – Section 4 4
Copyright © Innovative Technology Ltd 2012 GA963-2
The NV11 is a LIFO (Last In First Out) system. This means that only the last note in
the Note Float module is available to be paid out or moved to the stacker. Any value
note can be routed into the Note Float module using the ‘Set Routing’ command. It is
recommended that only one denomination of the chosen currency is stored in the
Note Float module.
The NV11 validator is pin for pin compatible with
the NV7 / NV8 / NV9 / NV10 series of validators,
but NOT with earlier versions of the product
(NV2 – NV5).
The NV11 validator leaves the factory preset to at least one currency and dataset so
that it is ready for immediate installation. The NV11 validator works with any NV9USB
currency dataset created by Innovative Technology Ltd - datasets can be downloaded
from the Support section of the ITL website.
