The NV11 Validator leaves the factory preset
to at least one currency and one interface so
that it is ready for immediate installation. The
dataset and interface used are shown on the
label fixed to the front of the Note Float unit.
1.6 Status Indicators
The NV11 validator has two separate coloured Light Emitting Diode (LED) indicators
that are used to show the status of the unit – these are located next to the
configuration button on the front of the Note Float module, and behind the front bezel
of the NV9USB validator head.
If there is a fault or other issue with the unit, the LEDs will flash as described in
subsection 1.9.
1.7 Programming
Full details on programming the NV11 validator can be found in Section 3 of this
manual set (ITL Software Support Guide).
Action
Power Status
Function
Press and hold (more than
2 seconds) until the bezel
illuminates, then release
Powered ON
Sets validator to Programming
mode (SSP)
Press twice (within half a
second)
Powered ON
Shows current interface type (see
flash count table below)
Press once when Note
Float module status LED is
flashing (transport error)
Powered ON
Acknowledges that a note
blockage has been cleared
Flash Count
Interface
1
SSP
6
ccTalk
6 , 1
ccTalk plain (16 bit)
6 , 1 , 2
ccTalk (8 bit)
