NV11 Manual Set – Section 4 19
Copyright © Innovative Technology Ltd 2012 GA963-2
CN215 Parts List
Qty
Description
Supplier
Alternative
2
8 way 2 row 2.54mm pitch friction lock housing
Leotronics 2652-2161
Molex 90142-0016
8
Tin plated crimp socket 22-24 AWG
Leotronics 2653-2000
Molex 90119-0110
2
Black heat shrink sleeving
---
---
1
22 AWG stranded 4 core cable, PVC insulated
---
---
CN215 Connectivity
CON1
CON2
Gauge
Colour
Comments
Pin
1
1
24 AWG
Orange
5
5
24 AWG
Brown
15
15
24 AWG
Red
V IN
16
16
24 AWG
Black
GND
Notes:
Pins 3, 4, 7, 8, 9, 10, 13 and 14 have no crimps fitted
Pins 2, 6, 11 and 12 have crimps fitted but these are not connected.
WARNING!
Use correct wire
gauges
If you choose to make your own cables, you must make sure that the wire gauges are suitable for use
with the validator. The minimum wire gauge for the CN292 cable is 24 AWG, with 22 AWG being
recommended.
