CN392 Parts List
Qty
Description
Supplier
Alternative
1
USB 2.0 lead with type A plug
Molex 88728-3400
RS 324-8362
2
8 way 2 row 2.54mm pitch friction lock housing
Molex 90142-0016
Leotronics 2652-2161
9
Gold plated crimp socket 22-24 AWG
Molex 90119-2110
Leotronics 2653-2000
2
Black heat shrink sleeving
---
---
2
26 AWG stranded single core cable, PVC insulated
---
---
CN392 Connectivity
CON1
CON2
Gauge
Colour
Comments
Pin
1
13
Red
USB +V (+5V)
2
12
White
USB Data – (twist together with Data +)
3
11
Green
USB Data + (twist together with Data -)
4
16
Black
USB GND - see figure 1 for connection detail
Screen
16
Black
See figure 1 for connection detail
---
16
26 AWG
Black
0V - see figure 1 for connection detail
---
15
26 AWG
Red
+12V - see figure 1 for connection detail
Notes:
CON2 pins 1 - 4 have crimps fitted but these are not connected.
CON2 pins 5 -10 and 14 have no crimps fitted
WARNING!
Use correct wire
gauges
If you choose to make your own cables, you must make sure that the wire gauges are suitable for use
with the validator. The minimum wire gauge for the CN392 cable is 26 AWG, with 24 AWG being
recommended.
