Innovative Technology NV11 - Page 137

NV11 Manual Set – Section 5 4
Copyright © Innovative Technology Ltd 2012 GA963-2
NV11 SSP Interface:
Pin
Name
Type
Description
1
TxD
Output
Serial data out (Tx)
2
Factory use only
Do not connect
3
4
5
RxD
Input
Serial data in (Rx)
6
Factory use only
Do not connect
7
8
9
10
11
USB D+
Data
USB Data +
12
USB D-
Data
USB Data -
13
USB Vcc
Power
USB +V (+5V)
14
Factory use only
Do not connect
15
V In
Power
+V
16
GND
Ground
GND
NV11 ccTalk Interface:
Pin
Name
Type
Description
1
TxD
Output
ccTalk data – must also be
connected to pin 5
2
Factory use only
Do not connect
3
4
5
RxD
Input
ccTalk data – must also be
connected to pin 1
6
Factory use only
Do not connect
7
8
9
10
11
USB D+
Data
USB Data +
12
USB D-
Data
USB Data -
13
USB Vcc
Power
USB +V (+5V)
14
Factory use only
Do not connect
15
V In
Power
+V
16
GND
Ground
GND
