NV11 Manual Set – Section 5 7
Copyright © Innovative Technology Ltd 2012 GA963-2
Action
Command Code (Hex)
Command Set
Enable Protocol Version
Events
0x19 (made obsolete in
protocol version 6)
Validator
Get Bar Code Reader
Configuration
0x23
Set Bar Code Reader
Configuration
0x24
Get Bar Code Inhibit
0x25
Set Bar Code Inhibit
0x26
Get Bar Code Data
0x27
Enable Payout Device *
0x5C, Options
Note Float
Disable Payout Device
0x5B
Set Routing *
0x3B (route, value/channel
(Country code))
Get Routing *
0x3C (value/channel (Country
code))
Empty
0x3F
Get Note Positions *
0x41
Payout Note
0x42
Stack Note
0x43
Set Value Reporting Type *
0x45 (type)
SMART empty
0x52
Cashbox Payout Operation
Data
0x53
The commands marked with * will respond with the generic response ‘Command
cannot be processed’ and an error code of ‘Invalid Currency’ if there are notes inside
the Note Float module that do not match the dataset that is installed in the validator.
