Diagnostics Fail:
Further details on how to use the diagnostics tools and interpret the results can be
found in the program help file.
Motor test results are shown in
this window – in this example all
the motors have passed testing.
Sensor test results are shown in this
window – in this example, several sensors
have failed during the diagnostics test.
A summary of the validator type and
related information is displayed here.
The overall test result is displayed here.
