2.4.4.1 Configuration Button Press Functions
2.4.4.2 Bezel Interface Flash Counts
The NV9 Spectral Validator leaves the factory pre-set to at least one currency and
one interface so that it is ready for immediate installation. The dataset and interface
used are shown on the label fixed to the top of the upper housing assembly.
Action
Power status
Function
Press and hold (more than 3 seconds)
until the bezel illuminates, then release
Powered ON
Sets validator to SSP
commonly known as
programming mode
Press twice (within half a second)
Powered ON
Shows current interface
type (see flash count
table below)
Press and hold as validator is powered
up
Powered OFF /
ON
Resets to factory
settings
Release front catch and open pathway
and apply power, then press and hold
(more than 3 seconds) until red LED
lights up front right.
Powered OFF /
ON
DES Trusted Mode
Information
CcTalk/CC4, CC2 and SSP
are currently implemented
Flash Count
Interface
1
SSP
6
CC4/ CC2
