4.4.2 Cashbox fitting (slide on cashbox)
1. Positioning the cashbox for fitting
Firstly, ensure the cashbox hooks are aligned with the accommodating grooves on
the main housing assembly. Thereafter push the cashbox hooks into place.
2. Sliding the cashbox into place
Ensure the cashbox hooks are aligned and inserted into the accommodating grooves
on the under-housing assembly.
Ensure the
cashbox clears
the release
catch on the
housing
assembly
