Power Requirements
3.4.1 Supply Voltages
Supply Voltage
Minimum
Nominal
Maximum
Supply Voltage (V DC)
+ 10.8 V DC
+ 12 V DC
+ 13.2 DC
Supply Ripple Voltage
0 V
0 V
0.25 V @ 100 Hz
3.4.2 Supply Currents
Phase of operation
Current draw (max)
Standby
200mA
Running (RMS)
1 A
Peak
3 A
3.4.3 Power Supply Guidance
The NV9 Spectral requires a stable 12 V DC / 3 A power supply. Check the power
requirements of the host machine and other peripherals to dimension a suitable
power environment for the machine setup.
Caution!
Power must always be connected.
TDK Lambda manufactures suitable power supplies. See table below for further
details.
Power Supply Unit
Specification
RS Stock Code
Farnell Stock Code
TDK Lambda RWS-50B-12
+12 V DC / 4.3 A
839-9626
2452725
TDK Lambda LS75-12
+12 V DC / 6 A
680-2773
1657444
Interface Logic Levels
Interface Logic Levels
Logic Low
Logic High
Inputs
0V to +0.5V
+3.7V to +12V
Outputs with 2K2Ω pull-up resistor
+0.6V
Pull-up voltage of host interface
Maximum Current Sink
50mA per Output
