4.5 Removing the Blanking Plate
1. Opening NV9 Spectral
Before removing the blanking
plate, the validator head will
need to be opened, push the
release catch and lift the
validator head.
2. Latch Release
Pull the release catch on each
side.
3. Lift Blanking Plate
With latches release lift the
blanking plate
1
2
1
