2.4.2 NV22
Rainbow Bezel
Note Path Release
Catch
Lozenge Locking
Clip Slot
300 Note Clip-on Cashbox
Manual Winding
Key
Multi Note Float release
tabs
Bezel release catch
Manual winding socket
Multi Note Float
(MNF)
Status LED and
Configuration Button
Last note window
(TOP)
