5.4.1.3 Hardware Setup
Connect the power supply to the DA2/IF17. Connect one side of the A to B USB
cable to the DA2/IF17 and the other end to the computer or laptop.
5.4.1.4 Switching to Programming Mode (SSP)
Before programming via validator Manager, the NV9S/NV22 needs to be switched to
its programming mode (SSP interface). Refer to 2.4.4 for the procedure for doing
this.
5.4.1.5 Programming the device
Once the unit has been switched to SSP, open Validator Manager and click detect
devices. This will scan all active com ports for a unit, if the NV22 fails to connect,
ensure the correct drivers are installed and the unit is in SSP.
