Commissioning and Trial Run
‑44‑
2.2.5 Motor Parameter Settings
Parame
ter
Code
Parameter
Name
Value Range Description
F1‑00
Motor type
0: Common
asynchronous
motor
1: Variable
frequency
asynchronous
motor
2: Permanent
magnet
synchronous motor
(PMSM)
3: Reluctance motor
without permanent
magnet
4: Electromagnetic
coil
A variable frequency motor can adjust its frequency and speed according
to the load. When the voltage is low, it can reduce the frequency and start
reliably. When the load is light, it can reduce the frequency, speed, and
current to save electric energy.
A common asynchronous motor is suitable for applications with normal
voltage but often full load. It is designed based on constant frequency and
voltage. Therefore, it may not meet all the frequency and speed control
requirements.
The reluctance motor is a synchronous motor without permanent magnet,
whose torque output is purely from the magnetic reluctance generated
from q/d‑axis inductance.
The electromagnetic coil is mainly used for electromagnetic stirring
equipment. No rotor is equipped and the motor is used to produce
rotating magnetic field.
F1‑01
Rated motor
power
0.1 kW to 1000.0 kW
The rated motor power indicates the axis output power of the motor
working in rated conditions. Select a motor with a proper power rating on
the premise that the motor can meet the requirements of mechanical
load. Take the motor heat dissipation, allowable overload capacity, and
starting capacity into account.
F1‑02
Rated motor
voltage
1 V to 2000 V
The rated motor voltage indicates the voltage of the motor during normal
operation, which usually refers to the line voltage.
F1‑03
Rated motor
current
0.01 A to 655.35 A
(AC drive power ≤
55 kW)
0.1 A to 6553.5 A (AC
drive power > 55
kW)
The rated motor current indicates the current of the motor during normal
operation, which usually refers to the line current.
F1‑04
Rated motor
frequency
0.01 Hz to F0‑10
The rated motor frequency indicates the frequency of the power supply
connected to the stator winding under the rated operation conditions of
the motor.
F1‑05
Rated motor
speed
1 RPM to 65535 RPM
The rated motor speed indicates the speed (r/min) of the rotor when the
motor is running under rated conditions.
F1‑06
Asynchro
nous motor
stator
resistance
0.001 Ω to 65.535 Ω
(power ≤ 55 kW)
0.0001 Ω to 6.5535 Ω
(power > 55 kW)
The motor stator resistance is the DC resistance of the motor stator
winding, which can be obtained through motor auto‑tuning.
F1‑07
Asynchro
nous motor
rotor
resistance
0.001 Ω to 65.535 Ω
(power ≤ 55 kW)
0.0001 Ω to 6.5535 Ω
(power > 55 kW)
The motor rotor resistance is the DC resistance of the motor rotor
winding, which can be obtained through motor static or dynamic auto‑
tuning.
To Next Page
