Commissioning Tools
‑21‑
1.2 Related Parameters
Table 1–5 Parameters related to the operating panel
Pa
rame
ter
Code
Parameter Name De
fault
Value Range Description
F7‑01 MF.K key function 0 0: MF.K key disabled
1: Forcibly change to operating
panel control
2: Switchover between forward
running and reverse running
3: Forward jogging
4: Reverse jogging
The MF.K key is a multi‑functional key. This
parameter is used to set the function of the MF.K
key.
0: MF.K key disabled
The key has no function.
1: Forcibly change to operating panel control
If F0‑02 is set to 0 (operating panel), the MF.K key is
unavailable. If F0‑02 is set to 1 (terminal), 2
(communication), or 3 (self‑defined control mode),
pressing the MF.K key forcibly changes the
command source to the operating panel.
2: Switchover between forward running and
reverse running
Pressing the MF.K key can switch frequency
reference directions. This function is valid only
when the command source is set to the operating
panel.
3: Forward jogging
Pressing the MF.K key enables forward jogging
(FJOG). This function is valid only when the
command source is set to the operating panel.
4: Reverse jogging
Pressing the MF.K key enables reverse jogging
(RJOG). This function is valid only when the
command source is set to the operating panel.
F7‑02 STOP/RES key
function
0 0: Valid only in the operating
panel control mode
1: Valid in any control mode
and OFF1 command‑based
stop
2: Valid in any control mode
and OFF2 command‑based
stop
3: Valid in any control mode
and OFF3 command‑based
stop
The STOP/RES key on the operating panel is used
to stop/reset the AC drive. This parameter is used
to set the function of the key.
0: The STOP/RES key is valid only in the operating
panel control mode.
1: The STOP/RES key is valid in any operating
mode, and the AC drive stops according to the
OFF1 stop mode.
2: The STOP/RES key is valid in any operating
mode, and the AC drive stops according to the
OFF2 stop mode.
3: The STOP/RES key is valid in any operating
mode, and the AC drive stops according to the
OFF3 stop mode.
