Commissioning and Trial Run
72
2.2.20(Optional) AO Settings
Parameter
Code
Parameter Name Default Value Range Description
F5‑07
AO1 output function
selection
0
0: Running frequency
1: Frequency reference
2: Output current
3: Output torque (absolute value)
4: Output power
5: Output voltage
6: Pulse input
7: AI1
8: AI2
9: AI3
10: Length
11: Count value
12: Communication setting
13: Motor speed
14: Output current (100%
corresponding to 1000 A
)
15: Bus voltage (100% corresponding to
1000 A
)
16: Output torque (actual value)
Others: F connector
See below.
F5‑08
Output function
selection of AO2 on
expansion card
1
Table 2–5 Description
Value Function Range
0 Operating frequency 0 to Maximum output frequency. The value 100.0% corresponds to the
maximum frequency (F0‑10).
1 Frequency reference 0 to maximum output frequency
2 Output current 0 to two times the rated motor current. The value 100.0% corresponds to
two times the rated motor current.
3 Motor output torque 0 to rated motor torque. The value 100.0% corresponds to the rated
motor torque (absolute value).
4 Output power 0 to two times the rated motor power. The value 100.0% corresponds to
two times the rated motor power.
5 Output voltage 0 to 1.2 times the rated motor voltage. The value 100.0% corresponds to
1.2 times the rated motor voltage.
6 Pulse input 0.01 kHz to 100.00 kHz. The value 100.0% corresponds to 100.00 kHz.
7 AI1 ‑10 V to +10 V. The value 100.0% corresponds to 10 V.
8 AI2 ‑10 V to +10 V (or 0 mA to 20/40 mA). The value 100.0% corresponds to 10
V.
9 AI3 ‑10 V to +10 V. The value 100.0% corresponds to 10 V.
10 Length 0 to maximum length. The value 100% corresponds to FB‑05.
