Inovance MD520 Series Commissioning Guide

Commissioning and Trial Run
‑46‑
Parame
ter
Code
Parameter
Name
Value Range Description
F1‑28
Encoder type
0: ABZ incremental
encoder
1: 23‑bit encoder
2: Resolver
Encoders are classified into incremental encoders and absolute encoders.
● An incremental encoder converts displacement into periodic electrical
signals, which are then converted into pulses that are counted. That is,
the magnitude of displacement is expressed as the number of pulses.
● An absolute encoder maps each position to a digital code. Therefore, its
indication is related only to the start and end positions of the
measurement, but is not related to any intermediate process of
measurement.
F1‑29
PG signal
filter
0: Non‑adaptive
filter
1: Adaptive filter
2: Fixed interlock
3: Automatic
interlock
‑
F1‑30
Encoder
wiring flag
Ones position: AB
signal direction or
rotational direction
Tens position:
Reserved
‑
F1‑31
Encoder zero
position
angle
0.0°to 359.9° ‑
F1‑32
Numerator of
motor gear
ratio
1–65535 ‑
F1‑33
Denominator
of motor gear
ratio
1–65535 ‑
2.2.6 Motor Parameter Auto-tuning
Enter motor parameters (F1‑00 to F1‑05) correctly according to its nameplate. Set F1‑
37 to 1 (asynchronous motor static auto‑tuning) and press ENTER. The operating
panel displays TUNE. Press the RUN key. The motor auto‑tuning starts. When the
operating panel displays 50.00, the auto‑tuning is completed. Then parameters F1‑06
to F1‑10 are obtained and written.
