Inovance MD520 Series Commissioning Guide

Commissioning and Trial Run
‑74‑
2.2.21(Optional) DI Settings
Parame
ter
Code
Parameter Name Default Value Range Description
F4‑00 DI1 function
selection
1 0: No function
1: Forward run (IN1)
2: Reverse run (IN2)
3: Three‑wire control (IN3)
4: Forward jog (FJOG)
5: Reverse jog (RJOG)
6: Function as UP key for
frequency adjustment
7: Function as DOWN key for
frequency adjustment
8: Coast to stop
9: Fault reset (RESET)
10: Running pause
11: NO input of external fault
12: Multi‑reference terminal 1
13: Multi‑reference terminal 2
14: Multi‑reference terminal 3
15: Multi‑reference terminal 4
16: Terminal 1 for acceleration/
deceleration selection
17: Terminal 2 for acceleration/
deceleration selection
18: Frequency source
switchover
19: Clear data set by UP/DOWN
key or by terminal functioning
as UP/DOWN key
20: Command source
switchover terminal 1
21: Acceleration/Deceleration
inhibited
22: PID pause
23: Simple PLC state reset
24: Wobble frequency pause
25:Counter input
26: Counter reset
27: Length count input
28: Length reset
29: Torque control inhibited
30: Pulse frequency input
(available only for DI5)
31: Reserved
32: Immediate DC braking
33: NC input of external fault
34: Frequency modification
function
35: Opposite to PID operation
direction
36: External stop terminal 1
37: Control command switchover
terminal 2
38: PID integral pause
39: Switchover between main
frequency X and preset frequency
40: Switchover between auxiliary
frequency Y and preset frequency
41: Motor selection terminal 1
42: Reserved
43: PID parameter switchover
44: User‑defined fault 1
45: User‑defined fault 2
46: Speed control/Torque control
selection
47: Emergency stop
48: External stop terminal 2
49: Decelerate to DC braking
50: Clear the current running
time
51: Two‑wire/Three‑wire control
mode switchover
52: Reverse running inhibited
64: Forward limit switch
65: Reverse limit switch
66: Water cooling fault input
67: Low‑liquid fault input
To be continued
See
descrip
tions
below.
F4‑01 DI2 function
selection
4
F4‑02 DI3 function
selection
9
F4‑03 DI4 function
selection
12
F4‑04 DI5 function
selection
13
F4‑05 DI6 function
selection
0
F4‑06 DI7 function
selection
0
F4‑07 DI8 function
selection
0
F4‑08 DI9 function
selection
0
F4‑09 DI10 function
selection
0
