Inovance MD520 Series Commissioning Guide

Commissioning Tools
‑24‑
Pa
rame
ter
Code
Parameter Name De
fault
Value Range Description
FP‑02 Display of
function
parameter groups
63 Bit 00: Group U
0: Hidden
1: Displayed
Bit 01: Group A
0: Hidden
1: Displayed
Bit 02: Group B
0: Hidden
1: Displayed
Bit 03: Group C
0: Hidden
1: Displayed
Bit 04: Group H
0: Hidden
1: Displayed
Bit 05: Group L
0: Hidden
1: Displayed
This parameter is used to determine whether the
parameter groups U, A, B, C, H, and L are displayed
on the operating panel.
The value 1 of a bit indicates that the parameter
group is displayed.
The value 0 of a bit indicates that the parameter
group is not displayed.
FP‑03 Display of user
parameters
111 Ones position:
0: Hide user mode
1: Show user mode
Tens position:
0: Hide calibration mode
1: Show calibration mode
Hundreds position:
0: Hide error menu
1: Show error menu
This parameter is used to determine whether the
user‑customized parameter group, user‑modified
parameter group, and error menu are displayed on
the operating panel.
1.3 Parameter Settings
The operating panel provides three levels of menus for parameter settings. You can
press
, , , and to modify the blinking bit on a menu of the
operating panel. The three levels of menus are described as follows:
● Level‑1 menu: parameter groups
● Level‑2 menu: parameters
● Level‑3 menu: parameter value settings
For example, to change the value of F3‑02 from 10.00 Hz to 15.00 Hz, perform settings
according to the following figure.
