Commissioning Tools
‑30‑
Table 1–6 MF.K key parameter descriptions
Pa
rame
ter
Code
Parame
ter Name
Default Value Range
Description
F7‑01
MF.K key
function
0
0: MF.K key
disabled
1: Forcibly
change to
operating
panel control
2: Switchover
between
forward
running and
reverse running
3: Forward
jogging
4: Reverse
jogging
The MF.K key is a multi‑functional key. This
parameter is used to set the function of the
MF.K key.
0: MF.K key disabled
The key has no function.
1: Forcibly change to operating panel
control
If F0‑02 is set to 0 (operating panel),
pressing the MF.K key produces no effect. If
F0‑02 is set to 1 (terminal), pressing the
MF.K key can implement switchover
between terminal control and operating
panel control. If F0‑02 is set to 2
(communication), pressing the MF.K key
can implement switchover between
communication control and operating
panel control.
2: Switchover between forward running
and reverse running
Pressing the MF.K key can switch between
frequency reference directions. This
function is valid only when the command
source is set to the operating panel.
3: Forward jogging
Pressing the MF.K key enables forward
jogging (FJOG). This function is valid only
when the command source is set to the
operating panel.
4: Reverse jogging
Pressing the MF.K key enables reverse
jogging (RJOG). This function is valid only
when the command source is set to the
operating panel.
1.8 Driving the Motor with the Operating Panel
You can press on the operating panel to enable the motor to jog forwardly or
reversely, and press
or to start or stop the motor.
PPrroocceedduurree
