Commissioning and Trial Run
‑61‑
2.2.16(Optional) Startup Frequency Settings
Parame
ter
Code
Parameter
Name
Default Value Range Description
F6‑03
Startup
frequency
0.00 Hz
0.00 Hz to 10.00 Hz
This parameter defines the startup frequency for direct start
of the AC drive. When the startup frequency is higher than the
frequency reference, the AC drive will not start but stay
standby.
F6‑04
Startup
frequency hold
time
0.0s
0.0s to 100.0s
This parameter defines the hold time during which the
output frequency remains at the startup frequency. After this
hold time expires, the AC drive will accelerate from the
output frequency to the frequency reference.
2.2.17(Optional) S-curve Settings
Parame
ter
Code
Parameter Name Default Value Range Description
F6‑07
Acceleration/
Deceleration mode
0
0: Linear
acceleration/
deceleration
1: S‑curve
acceleration/
deceleration
This parameter defines the frequency change mode during
the AC drive start and stop process.
0: The output frequency increases or decreases linearly.
1: When the target frequency changes dynamically in real
time, the output frequency increases or decreases based on
the S‑curve. This mode is applicable to applications requiring
smooth running and quick response in real time.
F6‑08
Time proportion of
S‑curve start
segment
30.0%
0.0% to
(100.0% to F6‑
09)
The sum of F6‑08 (Time proportion of S‑curve start segment)
and F6‑09 (Time proportion of S‑curve end segment) must be
lower than or equal to 100%.
F6‑09
Time proportion of
S‑curve end
segment
30.0%
0.0% to
(100.0% to F6‑
08)
The sum of F6‑08 (Time proportion of S‑curve start segment)
and F6‑09 (Time proportion of S‑curve end segment) must be
lower than or equal to 100%.
