Commissioning and Trial Run
‑75‑
Parame
ter
Code
Parameter Name Default Value Range Description
Contin
ued
Continued Contin
ued
Continued
70: Control channel selection
71: Setting channel selection
(reserved)
72: Terminal module A/B
selection
73: Start mode (bit 0)
74: Start mode (bit 1)
75: Control command
switchover terminal 3
76: Motor selection terminal 2
77: Running permission
78: Forward running permission
79: Reverse running permission
80: Set RFG input to zero
86: Breakage detection (wire
drawing machine)
Continued
Note
Function 30 (pulse frequency input) is available for F4‑04 but not available for F4‑00 to F4‑
03 and F4‑05 to F4‑09.
0: No function
No function is assigned to the DI.
1: Forward run (IN1)
The terminal is used to set the AC drive to run forwardly. In two‑wire operation mode
1 (F4‑11 = 0), activating DI function 1 triggers forward run. In two‑wire operation mode
2 (F4‑11 = 1), activating DI function 1 triggers an operation command.
2: Reverse run (IN2)
The terminal is used to set the AC drive to run reversely. In three‑wire operation mode
1 (F4‑11 = 2), activating DI function 2 triggers reverse run. In three‑wire operation
mode 2 (F4‑11 = 3), activating DI function 2 triggers forward/reverse run.
3: Three‑wire control (IN3)
The DI is used to set the three‑wire control mode for the AC drive. To set the running
command source to the terminal, set F4‑11 (Terminal command mode) to 2 (Three‑
wire mode 1) or 3 (three‑wire mode 2), and set the DI to function 3. The three‑wire
control modes include three‑wire mode 1 and three‑wire mode 2.
4: Forward jog (FJOG)
The terminal is used to set the AC drive to jog forwardly. In the jogging mode, the
drive runs at a low speed temporarily, which is generally used for maintenance and
commissioning of the equipment on site.
5: Reverse jog (RJOG)
The terminal is used to set the AC drive to jog reversely.
