Commissioning and Trial Run
‑50‑
Parame
ter
Code
Parameter
Name
Default Value Range Description
Contin
ued
Continued Contin
ued
Continued Continued
7: Simple PLC
Simple PLC is a multi‑reference used to control the running time
and acceleration/deceleration time. Parameters FC‑00 to FC‑15
are used to set the values of each frequency. FC‑18 to FC‑49 are
used to set the running time and acceleration and deceleration
time of each frequency. Up to 16 speeds can be set.
8: PID
PID is selected as the main frequency source. As a general
process control method, PID control is a closed‑loop mechanism
in which each controlled variable is stabilized at the target level.
This is implemented through proportional, integral, and
differential calculation of the difference between the feedback
signal and the target signal of the controlled variable and
through adjustment of the AC drive output frequency. PID
control is generally used in closed‑loop control scenarios, such
as constant pressure closed‑loop control and constant tension
closed‑loop control.
9: Communication
The main frequency is set through communication. The
frequency reference can be input through remote
communication. The AC drive must be equipped with a
communication card to communicate with the host controller.
This mode is suitable for remote control or centralized control
on multiple equipment.
Others: F connector
This parameter is set to the number of a floating connector. In
this case, the value of the connector is read as an auxiliary
frequency reference. It is used for extension of common sources.
