Ancillary parts
Product Support: www.instron.com
If you suspect that a cell may be damaged, contact Instron
®
Service to arrange return of
the load cell for analysis and possible repair.
Ancillary parts
This section lists the ancillary parts that are included with the system upon delivery.
These components are either required to complete the installation, or facilitate setting
up load cells and accessories on the load frame. Keep these components in a safe
place.
Parts list
Table 11. Ancillary parts
Description
Part
Number Quantity Purpose
Cable tie hook and loop 11-10-1027 5 Cable management
Cable clip, 6-12 mm 11-6-60 3 Secures cables to the frame
Screw, M10 x 40 201V57 2 Used to attach 2530 load cells and
2519 load cells of capacity greater
than 1kN.
Screw, M6 x 40 201V38 2 Used to attach 2519 load cells of
capacity up to 1kN.
Screw, M6 x 25 201V35 1 Attaches base adapter to frame
Pin 3mm diameter, 10mm long 705K84 5 Load cell anti-rotation pin
Locating ring T1335-1048 1 Locating ring for base - 40mm
diameter for M30 thread
M6 load washer T604-235 1 Adapter for M6 screws
Fuse, 5A time lag, 5 x 20mm P636-279 2 Protection from electrical surges
Thin open-ended wrench,
16mm/17mm
P632-482 1 Tool for adjustment of feet on load
frame
Combination wrench, 19mm P632-484 1 Tool for adjustment of feet on load
frame
M10 washer 610J9 2 Use with M10 screws for load cell
attachment
